The 3G-SDI/HDMI Full HD Genlock Camera with 4mm Fixed Lens from AIDA Imaging is an ultracompact camera suitable for web-conferencing, sports, auto racing, surveillance, medical, broadcasting, live production, education, house of worship, and other applications.
Key Features
- Capture up to 1080p60 Resolution Video
- C/CS Mount with 4mm Lens Included
- Auto Iris, 3G-SDI and HDMI Outputs
- Tri-Level Sync Genlock, Noise Reduction
- Wide Dynamic Range, White Balance
- RS-485 Input, Auto-Iris Lens Connector
- Breakout Cable with OSD Controls
- Embedded Audio, 3.5mm Analog Input
- Rugged, Compact Design
Specifications
Video
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Sensor Size | 5.346 x 3.003 mm (16:9) |
| Effective Pixels | 1920 x 1080 |
| Pixel Size | 2.75 x 2.75 µm |
| Video Resolution Supported | 1080p: 60, 59.94, 50, 30, 29.97, 25 1080i: 60, 59.94, 50 720p: 60, 59.94, 50, 30, 25 |
| Video Output Connectors | 1 x BNC, 3G-SDI 1 x HDMI 1.3a |
| Other I/O | 1 x 4-Pin, Auto-Iris |
| Breakout Cable Connectors | 1 x 3.5 mm, Analog Audio 1 x RS-485, Camera Control 1 x Power |
| Color Space | 4:2:2 YCbCr, 10-Bit |
| Minimum Illumination | 0.2 lux (Day) 0.1 lux (Night) 0.005 lux (Slow Shutter ON) |
| White Balance | 9000K to 11,000K |
| SMPTE | SMPTE 292M, SMPTE 424M |
Lens
| Focal Length | 4mm |
| Lens Mount | C/CS Mount |
Audio
| Sample Rate | 16/24/32-Bit |
General
| Genlock | External Tri-Level Input |
| Controls | RS-485, OSD Button on Breakout Cable |
| Power Source | 12 VDC (9 to 15 VDC), 6 W |
| Operation Temperature | 32 to 104°F / 0 to 40°C |
| Dimensions | With Default 4mm Lens: 1.92 x 1.92 x 2.79″ / 49 x 49 x 71 mm |
| Weight | With Default 4mm Lens: 6.3 oz / 180 g |
