The AIDA Imaging UHD-NDI3-IP67 is a compact NDI|HX3 / IP streaming weatherproof POV camera that brings high-resolution 4K IP and NDI video output into a wide range of environments such as outdoor broadcasting in challenging conditions.
A long cable carries multiple streaming protocols over a single Ethernet cable, as well as VISCA-over-IP for camera control. The camera can be powered using the included power adapter or by using the included PoE port on a PoE-supported network. It features a C/CS lens mount and comes with a 5mm 4K lens pre-installed.
Key Features
- Compact miniature camera for POV streaming applications in broadcast, education, medical, live production, sports, and other fields
- Weatherproof IP67 rating allows for extra protection against environmental elements
- 4K Ultra HD 1/2.8″ progressive scan CMOS sensor capable of up to 2160p60 NDI|HX video (NDI|HX3 limited to 1080p60 maximum)
- Accessible web UI to stream directly to social media platforms and control image parameters over IP
- Versatile design with top and bottom tripod mounts for unique shot creation
- Suited for outdoor shots and any new or existing NDI|HX setup
- C/CS lens mount
- 5mm 4K lens pre-installed
- VISCA-over-IP control support
Specifications
Video
- Image Sensor: 1/2.8” Progressive CMOS
- Effective Pixels: Horizontal: 1920, Vertical: 1080
- Pixel Size: 2.0 μm (H) x 2.0 μm (V)
- Resolution: 1080p, 1080i, 720p
- Resolution/Framerate: NDI HX only: 2160p 60p/59.94/50p/30p/ 29.97p/25p/24p; NDI|HX 3 and Others: 1080 60p/59.94/50p/30p/ 29.97p/25p/24p, 1080 60i/59.94i/50i, 720 60p/59.94p/50p
- Output: IP (NDI|HX3/SRT/RTMP/RTSP)
- Color Space: 4:2:2 (YCbCr) 10bit
- Min Illumination: 0.2Lux (day), 0.1Lux (Night)
- White Balance: Auto & Manual (9000 – 11,000 K)
Lens
- Lens: C/CS Mount (12MP Default 5mm UHD lens)
Physical
- Camera Control Protocol: VISCA Over IP
- Operation Temp: 32°F – 104°F
- Dimensions: 120mm x 53mm x 53mm / 4.72” x 2.09” x 2.09”
- Weight: 800g / 1.76 lb
- Power: 12VDC (+9 – +15VDC) (PoE Adapter Included)
