The AIDA Imaging UHD-NDI3-X30 features the ability to produce stunning NDI|HX3 at 1080p 60fps via its 4K Sony CMOS sensor, exhibiting the clearest Full-HD video over any HX3 network. If you need something a bit more, you can choose the camera’s 4K 60fps over NDI|HX, accounting for every detail possible in any frame. You also get the luxury of having a HDMI 2.0 port for output or field tests, set at any resolution you need it at.
Ignite your imagination with HD or 4K visual brilliance from the UHD-NDI3-X30, pushing the envelope of what is now, next-gen streaming!
Deliver power and stereo analog audio via the included breakout cable. Other image parameters are adjustable via WebUI. PoE+ support reduces cable runs for power, control, and video over a single cable. Update your camera’s firmware via the USB Type C port. A tally light indicator at the front of the camera lets your talent know when you’re live.
Features at a Glance
- WebUI streams directly to social media platforms and allows controlling image parameters via IP
- 30x optical zoom for 4K shots up to 150 feet (50 meters)
- I/O breakout cable with power and 3.5mm audio input
- Relay multi-channel embedded audio via NDI|HX and HDMI
- PoE+ compatibility reduces cable runs
- Two 1/4″-20 mounting threads
- Integrated front tally light
- Supports UDP|IP, RTSP, RTMP, SRT, and NDI|HX and NDI|HX3 protocols
Specifications
General
| Image Sensor | 1/2.8″ Progressive CMOS |
| Effective Pixels | 3840 x 2160 |
| Pixel Size | 2.0 x 2.0 μm |
| Resolution | 2160p, 1080p, 1080i, 720p |
| Frame Rates | NDI|HX and HDMI only: 2160 60p/59.94/50p/30p/ 29.97p/25p/24p NDI|HX3 and others: 1080 60p/59.94/50p/30p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
| Color Space | 4:2:2 YCbCr 10-bit |
| Minimum Illumination | 0.2 lux (Day), 0.1 lux (Night) |
| Zoom | 30x (Optical) |
| Focal Length | 6.91 ~ 214.64mm |
| Field of View | 59° (Wide) 1.98° (Tele) |
Inputs / Outputs
| USB I/O | 1 x USB Type C Female Input |
| Video I/O | 1 x HDMI Output 1 x RJ-45 Output |
| Audio I/O | 1 x 1/8″ / 3.5 mm TRS Input |
| Other I/O | None |
| Protocols | UDP|IP, RSTP, RTMP, SRT, NDI|HX |
| Audio Sample Rate | 16/24/32-bit |
| Control Protocol | VISCA over IP |
Power
| Power Source | AC Adapter with Power Brick (Included), PoE |
| DC Input Power | 12 VDC |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
Physical
| Mounting | 2 x 1/4″-20 Thread |
| Color | Black |
| Dimensions | 8.66 x 2.83 x 2.83″ / 220 x 72 x 72 mm |
| Weight | 3.09 lbs / 1400 g |
