AIDA Imaging UHD6G-X20L – 4Kp30 6G-SDI HDMI1.4 20X Zoom POV Camera
Original price was: $1,480.00.$1,184.00Current price is: $1,184.00.
BUY NOWCompact 4K POV Box Camera for Highly Detailed Visuals
The AIDA Imaging UHD6G-X20L brings professional-grade 4K capture to live production, broadcast, and fixed-installation environments. Its 1/1.7″ CMOS sensor and premium 20X zoom lens deliver sharp, detailed UltraHD video through both 6G-SDI and HDMI 1.4 outputs. This adds value to productions that may need different connectivity depending on the event or installation.
This compact POV camera fits seamlessly into demanding AV systems with support for serial VISCA, RS-485 control, and embedded audio. Integrators can deploy it in studios, houses of worship, corporate spaces, or performance venues where high-quality imaging and discreet placement matter.
With 10-bit 4:2:2 color, advanced noise reduction, and robust build quality, the UHD6G-X20L equips creators and organizations with a reliable tool for capturing clean, dynamic visuals in any professional setting.
Key Features
- 1/1.7″ high-resolution CMOS sensor
- 4K30 output over 6G-SDI and HDMI (simultaneous)
- 20× optical zoom lens for wide-to-telephoto coverage
- f/1.5–f/3.0 aperture for strong low-light performance
- 10-bit 4:2:2 color sampling
- Motion-compensated temporal noise reduction
- Line-level audio input with SDI audio embedding
- VISCA, IR, and RS-485 remote control options
- Compact POV form-factor with ¼-20″ mount
- Ideal for live streaming, broadcast, and fixed installations
Technical Specifications
| Image Sensor | 1/1.7″ Progressive CMOS |
| Effective Pixels (H × V) | 3840 × 2160 |
| Pixel Size | 1.85 µm (H) × 1.85 µm (V) |
| Resolution / Rates | 2160p 30/29.97/25/24 1080p 60/59.94/50/30/25/24 1080i 60/59.94/50i 720p 60/59.94/50 |
| Output | 6G-SDI / HDMI |
| Color Space | 4:2:2 (YCbCr), 10-bit |
| Min Illumination | 0.2 Lux (day), 0.1 Lux (night) |
| White Balance | Auto & Manual (9000 – 11,000 K) |
| Lens Module | 20× Optical Zoom, f/1.5 – f/3.0 |
| Field of View (FOV) | 61° – 3.4° |
| Audio Embed | Embed over SDI only |
| Audio Input | 3.5 mm Line Input |
| Control Protocol | Serial VISCA / RS-485 |
| Operating Temperature | 32 °F – 104 °F (0 °C – 40 °C approx) |
| Dimensions (W × H × D) | 68 mm × 146 mm × 68 mm (2.68″ × 5.74″ × 2.68″) |
| Weight | 750 g / 2 lb |
| Power | 12 V DC (+9 – +15 V DC) |
| Weight | 4 lbs |
|---|---|
| Dimensions | 17 × 7 × 7 in |
