Intinor Direkt link compact – Mobile SDI Encoder with 4G Cellular Uplink

The Intinor Direkt link compact is a mobile video encoder with low-latency for remote production over public internet. It offers latency as low as 0.5s with NTP stream synchronization when paired with Direkt receivers or routers. Transmission protocols include TCP, RTMP/RTMPS, and Intinor’s proprietary Bifrost™ (Bifrost Reliable Transport) protocol.

Build custom broadcasting and distribution workflows with options for HEVC (H.265), SRT and RIST encoding, additional NDI inputs, additional software encoding channels, VPN for remote PTZ, tally control, talkback, return video, basic video mixer, FTP upload, multiview, and more.

This rugged, fanless device features 2x 3G-SDI inputs, 1x MPEG4 AVC (H.264) software encoding channel (additional encoding channels are optional). Connections include 1x HDMI monitor out, 2x 4G SIM slots (with an option to add Heimdall Lite for more modems), 1x RJ-45 1Gbps Ethernet port, 1x RJ-45 2.5Gbps Ethernet port, plus built-in WiFi client and hotspot.

Powered is provided by an external DC or optional D-tap input for a battery via an adapter.

Compact, rugged fanless form-factor. 7.36″ L x 5.11″ W x 2.83″ H
