This 24-port POE switch from PTZCam Solutions combines high connection density with 10G Ethernet speeds to support a wide variety of power and data requirements.
This versatile Gigabit Ethernet network switch can be used as the backbone of a small television studio, church broadcasting setup, or school environment. Utilize it to power any number of POE+ devices like cameras, controllers, encoders, and more.
Features
- 24x RJ-45 Gigabit Ethernet copper ports
- 4x Fiber SFP+ slots (modules not included)
- POE/POE+ IEEE802.3af/at, Max. 30W/port
- 256Gbps total bandwidth
Specifications
| Port | 24*10/100/1000M |
| 4*10Gbps fiber SFP | |
| Management port | 1*Console |
| Reset KEY | 1 |
| Bandwidth | 256Gbps |
| Packet forwarding |
92.32Mpps |
| MAC |
16K |
| PoE port |
24 |
| PoE standards | IEEE802.3af/at, Max. 30W/port |
| Transmission Mode | Store and forward |
| Environmental | working temperature : 0℃~50℃ |
| Storage temperature : -40℃~70℃ | |
| Operating humidity : 10%~90% Non coagulation | |
| Storage humidity : 5%~95% Non coagulation | |
| Product size | 17.32″ L x 11.41″ W x 1.77″ H / 440mm L x 290mm W x 45mm H |
| Packing size | 19.56″ L x 15.47″ W x 3.83″ H / 497mm L x 393mm W x 97mm H |
| Weight | 11 lbs / 5kg |
| Power in |
AC 100~240V 50/60Hz |
| Power Consumption | Max. 400W |
| Lightning | Surge protection: 3KV 8/20us Grade: IP30 |
| Certificate | CCC; CE mark, commercial;CE/LVD EN60950; FCC Part 15 Class B; RoHS; |
| Warranty |
1 year |
