Flow Edge G 6CH – 6-Channel Video Conversion with Genlock

Up, Down, and Cross Conversion of Dozens of Digital Video Formats

The Flow Edge series from Science Image takes the versatility of the popular FLOW 4K and FLOW 2 converters and fits it into a single rack unit with centralized power. This makes building a multi-source, multi-destination rack kit that much easier. The Flow Edge design allows up to 6 channels of up/down and cross conversion of virtual any video format up to 4K at 60 fps, using both HDMI 2.0 and 12G-SDI connections.

Each channel of the Flow Edge has its own dedicated LED screen, menu control wheel, network port, video input/output, audio input/output, and power button. Choose from one to six channels in the same 1U, short-depth chassis.

The Flow Edge G series takes all of the above features and adds a Genlock sync input per channel.

Key Features

• 6-Channel Rack-mount 4K 12G-SDI/HDMI Up/Down/Cross converter with Fiber TX/RX and Analog Audio In/Out
• Up/Down/Cross Conversion of 35+ formats
• Video I/O: 6x 12G-SDI Inputs & Outputs, 6x HDMI 2.0 Inputs & Outputs, up to 2160p60, 6x Genlock inputs
• Audio I/O: 6x 3.5mm stereo headphone outputs, 5x 3.5mm stereo line-in inputs
• Display: 6x 1.3-inch OLED screen with status, video format, IP address, etc.
• Control: 6x Scroll wheel button for direct menu operation, Web UI control
• Audio function: Audio Embed/De-Embed from stream, 2-way Intercom per channel
• Network: 6x RJ-45 Gigabit Ethernet, 6x optical fiber SFP+ interfaces (for optional 12G-SDI transceiver)
• Power: AC power Inputs, 6x LED illuminated power buttons
