Science Image – Bundle with Two (2) NDI HD Mini Bi-Directional NDI Converters
$999.00
BUY NOWSpecial Bundle Price – Get two Science Image NDI HD Mini units at 15% off!
Description
Special Bundle Price – Get two Science Image NDI HD Mini units at 15% off!
Science Image NDI NDI HD mini Key Features:
- Bi-Directional SDI / HDMI Full NDI Encoder/Decoder
- 3G-SDI Input / Output, up to 1080p60; HDMI 2.0 Input / Output up to 2160p30
- 1.3-inch OLED screen with status, video format, IP address, etc.
- Large, semi-transparent tally light block
- Audio Embedd/De-Embed, Tally, Intercom, USB PTZ control
- RJ-45 Gigabit Ethernet network interface
- PoE or 12VDC power input
Technical Specifications
Video Format
| SDI video format | |
| SD/HD/3G-SDI video formats | 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60 |
| SDI specification | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10 |
| SDI video sampling | 4:4:4 |
| SDI audio sampling rate | 48kHz, 24-bit |
| SDI color accuracy | 4:4:4 |
| SDI color space | YUV and RGB |
| HDMI video format | |
| HDMI HD video formats | 525i29.97 NTSC, 625i25 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60 |
| 4K video format | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 |
| HDMI color space | YUV |
| HDMI color accuracy | 4:4:4 |
| Interfaces | |
| SDI video input | 1 x 1.5G/3G-SDI, adaptive input, automatic switching |
| SDI video output | 1 x 1.5G/3G-SDI, adaptive output, automatic switching |
| HDMI video input | 1 x HDMI 1.4 Type A interface supports up to HDMI 4K30p input, backward compatible |
| HDMI video output | 1 x HDMI 1.4 Type A interface supports maximum HDMI 4K30p output, backward compatible |
| LINE IN audio input port | 1 x LINE IN 3.5mm audio input port for external analog audio embedding |
| MIC Intercom input and output port | 1 x Mic 3.5mm audio input and output port (De-Embed), used for NDI Intercom (with Laudo software required) |
| USB 2.0 Type A port | 1 x USB 2.0 Type A interface, used to control a third-party PTZ camera |
| Display | |
| 1.3 inch OLED screen | 1 x 1.3-inch OLED screen, real-time display of NDI box encoding/decoding status, input/output format and IP and other information, clear at a glance, easy to operate |
| Tally Light | Large-size semi-transparent matte TALLY light guide block with three TALLY states transmitted through NDI in real time: Green/Preview, Red/Program |
| Network and requirements | Gigabit Ethernet switch and Gigabit Ethernet card. |
| Software, operating system, support platform | Built-in Linux, application control software Science Image Laudo. Supports Windows 8.1 and 10 operating systems, Mac 10.14 Mojave, Mac 10.15 Catalina or higher. Support IE/Edge/Firefox/Chrome/Safari/Opera and other browsers. |
| Physical | |
| size | 125mm x 95mm x 22mm |
| weight | 270g |
| material | aviation-grade milled aluminum |
| Power supply | |
| power supply requirements | Three power supply modes: 5-18V DC, POE (802.11af/at), USB |
| power consumption | 10W |
| Environmental | |
| Operating temperature | 5°C to 40°C |
| Storage temperature | -20° to 60° C (-4° to 140° F) |
| Relative humidity | 0% to 90% non-condensing |
| Packing List | NDI HD mini Quick start manual 12V universal power supply (includes four sets of international conversion plugs) |
| Warranty | 1 year limited manufacturer’s warranty |
Additional information
| Weight | 6 lbs |
|---|---|
| Dimensions | 12 × 8 × 6 in |
