Switchblade LPU2 4-channel SDI production platform
Power your favorite live production software with confidence
Creating high-quality live events is now more accessible and cost-effective thanks to popular software-based switching applications. However, despite the lowered entry barrier, these applications still demand powerful hardware for optimal performance. Consumer PCs, unfortunately, are not built for live production.
Switchblade Systems has become the trusted name for broadcast-ready production systems, catering to a wide range of productions from high schools to national broadcasters. The LPU2 production platform is engineered to deliver the perfect balance of performance, reliability, and flexibility for any broadcasting environment.
The LPU2 comes out of the box with Windows 11 Pro, ready to support most popular live switching software programs, including:
- StudioCoast vMix (meets the vMix “Ruby” Reference System specification)
- Telestream Wirecast
- Vizrt Viz Vectar
- Vimo Livestream Studio
- Open Broadcaster Software (OBS)
Technical Specifications
- Video Inputs & Outputs: 4x Bi-Directional 3G-SDI inputs/outputs, 1x reference inputs, 1x dedicated 3G-SDI/HDMI output
- Processor: 12-core Intel Core i7-12700KF
- System drive: 1TB NVMe PCIe Gen4 SSD
- Memory: 16GB DDR5 RAM
- Graphics: NVIDIA GeForce RTX 4060
- Operating System: Windows 11 Pro
- Network: 1x 2.5G Ethernet RJ-45 port
- Expansion: 2x 3.5″ front drive bays
- Form-factor: Rugged, short-depth 2U chassis
- Dimensions: 13.05″ D x 17.00″ W x 3.46″ H
- Weight: 18 lbs.
