Switchblade LPU2 – The ultimate vMix switcher solution for studio or remote production
The LPU2 is a compact, rackmount video switcher based on vMix live production software. Building off the success of Switchblade’s popular vMix turnkey systems, including the LPU4 and Turbo, the LPU2 packs all the essential features and I/O for running multi-camera, multi-source live broadcasts in any location.
Today’s live events rely increasingly on a combination of traditional physical inputs like HDMI and IP sources, including NDI and SRT. The LPU2 handles both with equal ease, packing four (4) HDMI inputs, a separate SDI/HDMI output, and vMix’s native support for NDI, NDI|HX, SRT, RTMP, and RTSP network video sources.
The compact, short-depth 2U chassis makes this tiny rack-mountable platform ideal for smaller studio rack spaces and transportable flypacks. Even setups without rack cabinets will find its diminutive size small enough to use on top of a desk.
Key Features
- Live switching of HDMI and network video inputs
- Includes perpetual license of vMix 4K software with 1 year of free version updates
- NDI input and output
- Up to 4096 x 2160 resolution (applies only to IP video inputs)
- 4 x HDMI outputs and 1 x 3G-SDI/HDMI output
- 4 x external display outputs for user interface, multiview, and more
- 4 x overlay channels for graphics, text, images, and more
- 2 x media recorders
- ISO recording on all HDMI inputs
- Simultaneous streaming to 3 destinations
- Integrates with Zoom for capturing individual participants
- GT Designer Standard and Advanced titling software included
- 4 x Remote callers with vMix Call feature
- 1-channel replay and slow-motion playback with vMix Replay (standalone app or inside vMix)
- PTZ camera control
Technical Specifications
- Form-factor: 2U rackmount/desktop
- Video Inputs: 4 x HDMI inputs, up to 1080p60
- Video Outputs: 1 x Full BNC 3G-SDI / HDMI combo output, up to 1080p60
- Display Outputs: 2 x DisplayPort 1.4a, 2 x HDMI 2.1a
- Analog Audio Inputs: 1 x 3.5mm (1/8″) line level stereo input, 1 x 3.5mm (1/8″) microphone level input
- Analog Audio Output: 1 x 3.5mm (1/8″) line level stereo output
- Digital Audio Inputs: 4 x HDMI stereo embedded digital audio inputs
- Digital Audio Outputs: 16x SDI embedded digital audio outputs, 8 x HDMI embedded digital audio outputs
- Processing: 12-core Intel Core i7-12700KF processor
- Graphics: NVIDIA GeForce RTX 4060 with 8GB GDDR6 VRAM
- Memory: 16GB DDR5
- Storage: 1TB NVMe SSD
- Network: 1 x 2.5Gb/s Ethernet RJ-45 port
- Operating System: Windows 10
- Dimensions: 17.00″ x 13.05″ x 3.46″ / 432mm x 331.5mm x 88mm
- Weight: 19 lbs / 8.6 kg
